Ortofon Cadenza Bronze Moving Coil Cartridge

Class Leading Dynamic and Tonal Neutrality

The Ortofon Cadenza Bronze boasts a Replicant 100 stylus and a conical aluminium cantilever. The coil wire used is the famous Ortofon Aucurum wire, which is a gold-plated version of the popular 6NX copper wire. A Field Stabilizing Element, FSE, is used for optimal linearity especially during complex crescendo passages, making this cartridge perfect for classical genres.

The Cadenza Bronze is a true high-end reference cartridge, conveying music with supreme precision, impact and dynamics. Its stereo imaging capabilities illuminate the farthest corners of the soundstage in all three dimensions, creating an uncompromising, involving performance.



Features and Benefits


Exceptional performance for price


Wide Range Damping System as used in the MC Anna and MC A95


Optimised for richer tonal character and dynamics


Ortofon Replicant 100 stylus and Aluminium Cantilever


Detailed Specifications:


Output Voltage (at 1kHz, 5cm/sec): 400μV


Channel Balance at 1kHz: < 1dB


Channel Separation at 1kHz: > 24dB


Channel Separation at 15kHz: > 20dB


Frequency Range (at -3dB): 20 Hz – 55kHz


Frequency Response 20Hz – 20kHz: +1.5


Tracking Ability at 315Hz: Typically 80μm


Compliance, Dynamic, Lateral: 12μm / mN


Stylus Type: Nude Ortofon Replicant


Cantilever: Conical Aluminium


Stylus Tip Radius r / R: 5 / 100μm


Tracking Force Range: 2.2 – 2.7g (22 – 27mN)


Recommended Tracking Force: 2.5g (25mN)


Tracking Angle: 23º


Internal Impedance / DC Resistance:


Recommended Load Impedance: 50 – 200Ω


Cartridge Body Material: Stainless Steel Aluminium


Cartridge Colour: Bronze / Black


Cartridge Weight: 10.7g
